Stock	Upon request
ISO Size	20FT ISO - 6058mm x 2438mm x 2591mm
Material Tank Body	Stainless Steel 316L

Approvals by Lloyd's Register, the Netherlands

20FT Diesel Tank Container

Download Technical Details
info@danteco.com
+31 10 351 00 22
Approved by international statutory authorities for the safe transportation of Bitumen, Asphalt, Emulsion and Heavy Crude Oil products

International statutory authorities approve Danteco's Diesel Tank Container 20FT ISO T11 for the safe transportation of Diesel Fuel UN1202 and Kerosene oil products. Danteco supplies 26,000 liters volume stainless steel diesel fuel tank containers 20FT ISO. Our ISO diesel tank container is separated into five purposes, tank containers for diesel storage, deep sea shipping, short sea, road trucking, and rail transportation. Danteco Tank Containers are of the highest quality design and construction and conform strictly to the latest international approvals.

Danteco supplies diesel fuel tank containers with 26,000-litre 20FT ISO, single-wall, and double-wall skin. Our diesel tank containers are separated for five purposes: tank containers for diesel storage, short-sea, deep-sea shipping, trucking, and rail transportation. All Danteco tanks have the highest quality design and construction and conform strictly to the latest international approvals.

Please note that in certain exceptional cases, the containers operated by Danteco may have specifications that differ from the descriptions above.

Also, cargo in the container must conform to the dimensional regulations and laws stipulated by the host country; thus, payload capacity may be affected. For more information or assistance, please contact our customer service.

Capacity: 26000L / 5719 Gallons (6868 US Gallons)
20FT ISO Frame
Full Frame Design
UN Portable T11 Code Design
Top Loading Point
Bottom Cabinet Stainless steel
TIR covers
DN80/100 Bottom Discharge
Approvals by Lloyds Register, the Netherlands.

DIESEL TANK 20FT ISO: 26000-Litre UN Portable Tank T11

Year manufactured: "new build."

Dimensions:
	Metric	Imperial
Capacity	26000 LTR	5719 GALLONS (6869 US Gallons)
Maximum Gross Weight	30480 KG	67196 LBS
Tare	5950 KG	13118 LBS
Construction:
Working Pressure	1.75 bar	25 psi
Test Pressure	2.65 bar	39 psi
Relief Valve Set Pressure	2.2 bar / -0.21 bar/vac.	32 psi / -3 vac./psi

Ambient Temp. Range	-40°C up-to +130°C	-40°F up-to +266°F
Maximum Cargo Temp	130°C	266°F
Shell Material	Mild Steel Q345D-GB/T1591-2008, 6,0 mm shell, 8,0 mm dish ends, the head is not less than 7,0 mm after forming.
Design Code / Approvals	ASME, section VIII, division 1 where applicable, and IMDG T11, DOT UK, USDOT, UIC, IMO2, FRA, CSC, ADR, RID, CTC Transport Canada
Standard Fittings:
Man-lid	Guard brand 500mm (20") diameter, 6-point fixing, 14mm x 12mm seal, located center.
Calibration	volumetric chart, nominal capacity 26,000 liters available
Airline / Vapor	Guard brand 40MM (1½") ball valve, outlet 1½" BSP, s/s screw cap.
Relief Valve	Guard brand 65MM (2½") high flow flanged, operating pressure 2,2 bar. Capacity: 8710m3/hr.
Top Inlet	Blanked weld-in flange drilled 6 M12 holes @ 168 pcd, provision for optional fitting of 80mm (3") stainless steel butterfly valve. DN80, ASA 150 bolted blank flange outlet, 80mm (3") with dust cap
Bottom Discharge	Guard 80MM swing foot bottom valve ball valve - Outlet 3" BSP Flange with 3" Cam-Lock Coupling and Dust-Cap.
Gaskets & Seals	Parts in contact with cargo, PTFE/Teflon.
Insulation	N/A of upon request
Document Holder / Earth	The fitted rear end is suitable for shipping documents, MSDS, etc. The Earth is located at the rear.
Data Plate / Markings	Stainless steel data plate detailing specifications fitted rear end.
Frame	The container frame shall be mainly composed of two (2) end frames, two (2) barrel supports, two (2) top side rails, two (2) bottom side rails, four (4) tank supports, and eight (8) corner fittings.
Walkway	400MM-wide non-slip steel. One longitudinal walkway and three short transverse walkways at the front and rear and adjacent to the rear of the manhole’s spill box. Aluminium walkways
Handrail	(Optional) Intergraded at the top rail
Temperature Gauge	Analogue gauge fitted rear end: -20°C to +150°C. / -4°F to +266°F
RAL Color / Paint Exterior	9010 - White, Custom Color, or Two Tone

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
