SPECIALISTS IN TANK CONTAINERS
Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil Bitumen Tank  HC Thermal-Oil
Stock Upon request
ISO Size 20FT HC - 6058mm x 2438mm x 2996mm
Material Tank Body Mild / Carbon steel

Danteco supplies 25,000-litre 20FT HC (high-cube) ISO bulk bitumen tank containers with a thermal-oil heating system (hot-oil) to be connected to the installation. Our bitumen tank containers are separated for four purposes: tank containers for bitumen storage, short-sea, deep-sea shipping, and rail transportation. All Delltank tanks have the highest quality design and construction and conform strictly to the latest international approvals.

Please note that in certain exceptional cases, the containers operated by Danteco Industries BV may have specifications that differ from the descriptions above.

Also, cargo in a container must conform to the dimensional regulations and laws stipulated by the host country. Thus, payload capacity may be affected. For more information or assistance, please contact our customer service.

  • Capacity: 25000L / (6604 US Gallons) 5500 Gallons Imp.
  • 20FT HC Full Frame T3 Tank Design
  • Design temp. -40°C up-to +200°C / -40°F up-to +392°F
  • Thermal Oil Heating System (Internal)
  • 3" and or 4" Bottom Discharge include 3” Cam-Lock coupling (m) & dust cap
  • Heavy Insulated 50mm
  • Approvals by Lloyd's Register, the Netherlands

SPECIFICATION: BITUMEN TANK CONTAINER THERMAL-OIL 20FT HC (HIGH-CUBE): 25000-Litre UN Portable Tank T3

6058mm x 2438mm x 2896mm high cube, 2.65 bar test pressure, insulated, flame tube type, direct fire, heating by a diesel burner or LPG gas burner

Dimensions:
  Metric Imperial
Capacity Tank 25000 LTR (6604 US GALLONS) 5500 GALLONS
Maximum Gross Weight 30480 KG 67196 LBS
Tare 5950 KG 13118 LBS
Construction:
Working Pressure 1.75 bar 25 psi
Test Pressure 2.65 bar 39 psi
Relief Valve Set Pressure 2.2 bar / -0.21 bar/vac 32 psi / -3 vac/psi
Ambient Temp. Range -40°C up to +200°C -40°F up to +392°F
Maximum Cargo Temp 230°C 446°F
Shell Material Mild Steel Q345D-GB/T1591-2008, 6,0 mm shell, 8,0 mm dish ends, the head is not less than 7,0 mm after forming.
Design Code / Approvals ASME, Section VIII, Division 1 where applicable and IMDG T3, DOT UK, USDOT, UIC, IMO2, FRA, CSC, ADR, RID, CTC Transport Canada.
Standard Fittings:
Manlid 500mm (20") diameter, 6-point fixing, 14mm x 12mm seal, located centre.
Calibration volumetric chart, nominal capacity 25,000 liters available.
Airline / Vapour 40MM (1½") ball valve, outlet 1½" BSP, s/s screw cap.
Relief Valve 65MM (2½") high flow flanged, operating pressure 2,2 bar. Capacity: 8710m3/hr.
Top Inlet Blanked weld-in flange drilled 6x M12 holes @ 168 pcd, provision for optional fitting of 80mm (3") stainless steel butterfly valve. DN80, ASA 150 bolted blank flange outlet, 80mm (3") removable full-length syphon tube.
Bottom Discharge Guard 100MM 4" Ball valve - Outlet 3" BSP Flange with 3" Cam Lock Coupling and 3" Dust Cap.
Gaskets & Seals Parts in contact with cargo, PTFE/Teflon.
Thermal-Oil (Hot-Oil) Type 14 pcs 2" seamless steel pipes are fitted at the bottom of the tank barrel, with a volume of 180 litres.
Insulation 50MM (2") inorganic Rockwool (CFC free); 1.0/1.2 mm aluminium sheel cladding; Thermal conductivity: ≤ 0.044 w/(m2.k).
Document Holder / Earth It is fitted at the rear end, suitable for shipping documents, MSDS, etc. The earth connection is located at the rear.
Data Plate / Markings Stainless steel data plate detailing specifications fitted rear end.
Frame The container frame shall be mainly composed of two (2) end frames, two (2) barrel supports, two (2) top side rails, two (2) bottom side rails, four (4) tank supports, and eight (8) corner fittings.
Walkway Aluminium 400MM-wide non-slip steel. One longitudinal walkway and three short transverse walkways at the front and rear and adjacent to the rear of the manhole’s spill box.
Handrail (Optional) Intergraded at the top rail.
Temperature Gauge Analog gauge fitted rear end: -20°C to +300°C. / -4°F to +572°F.

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
