Stock	Upon request
ISO Size	20FT HC PW - 6058mm x 2502mm x 2896mm
Material Barrel	Carbon / Mild Steel Q345R

CCS (China Classification Society)

ISO Powder Tank Container

Download Technical Details
info@danteco.com
+31 10 351 00 22
Approved by international statutory authorities for the safe transportation of dry bulk powders, hazardous and non-hazardous cargoes, and products

International statutory authorities approve the pneumatic-operated cement tank with the danteco aeration system for bulk powder cement to safely transport bulk cement, limestone, and fly ash powder products. Danteco Industries BV supplies various designs of the bulk 20FT bulk cement tank. Our cement tank is separated for four purposes: tank containers for cement storage, short-sea, deep-sea shipping, and rail transportation.

The powder tank containers are suitable for transporting bulk cement, limestone, fly ash, or coal powder by rail, road, and ship. All materials used in the construction shall withstand extremes of temperature ranging from -19ºC to +80ºC / -2,2ºF to +176ºF without affecting the strength of the container.

All Danteco tank containers are of the highest quality design and construction and conform strictly to the latest international approvals.

Please note that in certain exceptional cases, the containers operated by Danteco may have specifications that differ from the descriptions above.

Also, cargo in the container must conform to the dimensional regulations and laws stipulated by the host country; thus, payload capacity may be affected. For more information or assistance, please contact our office.

Loading Capacity 24.000 LTR
Tank Volume 28.000 LTR
20FT HC PW (High-Cube / Pallet Wide) ISO Full Frame Design
Design temp. -19ºC to +80ºC / -2,2ºF to +176ºF
Max. Gross Weight 34,000 kg / 74957 LBS
4" Cam-Lock male adaptor
Loading weight 29,550 kg / 65146 LBS
Applicable Standards and Approvals by CCS AS1210, ISO, TIR, TCT

SPECIFICATION: ISO POWDER TANK CONTAINER - DRY BULK CEMENT TANK 20FT HC PW

6058mm x 2502mm x 2896mm, 3.3 bar test pressure

Year manufactured: New Build

Dimensions:
	Metric	Imperial
Loading Capacity	24000 LTR	(6340 US GALLONS) 5279 GALLONS
Volume Capacity	28000 LTR	(7396 US GALLONS) 6159 GALLONS
Maximum Gross Weight	34000 KG	74957 LBS
Tare	4150 KG	9149 LBS
Construction:
Working Pressure	2.2 bar	32 psi
Test Pressure	3.3 bar	48 psi
Relief Valve Set Pressure	2.2 bar / -0.21 bar/vac	32 psi / -3 vac/psi
Ambient Temp. Range	-19°C up to +80°C	-2,2°F up to +176°F
Maximum Cargo Temp	80°C	176°F
Shell Material	Dia. 2480mm Cylindrical Shell Mild Steel Q345B, 4,0 mm shell, 6,0 mm dish ends.
Design Code / Approvals	ASME, Section VIII, Division 1 where applicable and TIR, C.S.C., ISO/TC - 104, ISO668, ISO6346, ISO830, ISO1496/3(Edt 2010), ISO1161, AS1210, TCT CCS. (China Classification Society).
Standard Fittings:
Manlid	3pc. 500mm (20") diameter, quick-release, 6 point fixing, 14mm x 12mm seal, located centre.
Air Source pressure	0.2~0.3 Mpa.
Air Supply	≥8 m3/min.
Air-inlet diameter	100mm cam lock type joint.
Outlet diameter	4" male adaptor.
The average speed of discharge (conveying cement to the place 30m high, 30m far)	Cement: 1.0~1.5 t/min.
Remnant Ratio	% cement: ≤0.3 (Cement: Not more than 100kg).
Gaskets & Seals	Parts in contact with cargo, PTFE/Teflon.
Pipe System	The dry compressed airflow via a 100 mm cam-lock type joint enters into the main pipe with a 2.5" one-way valve, a 2" safety valve, 1/2"safety valve, and a pressure gauge, then goes into two air cavities at each side of the inside of the tank through two branch pipes which separately connected to the tank and main pipe. Another airflow goes through a 1" ball valve and a 1" one-way valve into the unloading pipe to speed up unloading cement. The diameter of the main pipe is 76mm, and the branch pipe is 57mm.
Unloading pipe	4" steel pipe. One discharge butterfly valve and one 4" male adaptor are fixed on the discharge pipe.
Document Holder / Earth	Fitted @ the rear end, suitable for shipping documents, MSDS, etc. Earth is located at the rear.
Data Plate / Markings	Stainless steel data plate detailing specifications fitted rear end.
Frame	The frame comprises front and rear-ends frames, top and bottom. Each end frame is constructed by two (2) corner posts, top and bottom end rails, and four (4) thick diagonal corner plates. Side rails, two (2) barrel supports, two (2) saddles, and eight (8) corner fittings.
Walkway	400MM-wide non-slip steel. One longitudinal walkway and three short transverse walkways at the front and rear and adjacent to the rear of the manhole’s spill box. Steel-nets walkways galvanized to 10un thickness.
Handrail	(Optional) Intergraded at the top rail

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
