Stock	Upon request
ISO Size	Forklift 20FT HC - 6058mm x 2438mm x 2996mm
Material Tank Body	Mild /Carbon Steel

Approvals by Lloyd's Register, the Netherlands

Bitumen Tank Forklift HC Flame Tube

Download Technical Details
info@danteco.com
+31 10 351 00 22
Approved by international statutory authorities for the safe transportation of Bitumen, Asphalt, Emulsion, and Heavy Crude Oil products

Danteco supplies 25,000-liter 20FT HC (high-cube) with Reinforced Forklift Pockets equipped with bulk bitumen tank containers with pair (two) flame tubes. Our bitumen tank containers are separated for four purposes: tank containers for bitumen storage, short-sea, deep-sea shipping, and rail transportation. All Danteco tank containers are of the highest quality design and construction and conform strictly to the latest international approvals.

Please note that in certain exceptional cases, the containers operated by Danteco Industries BV may have specifications that differ from the descriptions above.

Also, cargo in a container must conform to the dimensional regulations and laws stipulated by the host country; thus, payload capacity may be affected. For more information or assistance, please contact our customer service.

Capacity: 25000L / (6604 US Gallons) 5500 Gallons Imp.
20FT HC Full Frame + Reinforced Forklift Pockets (only for empty handling)
T3 Tank Design
Design temp. -40°C up-to +200°C / -40°F up-to +392°F
Pair (two) Flame Tube Design (direct fire by diesel or LPG burner)
3" and or 4" Bottom Discharge include 3” Cam-Lock coupling (m) & dust cap
Heavy Insulated 50mm
Approvals by Lloyd's Register, the Netherlands

SPECIFICATION REINFORCED FORKLIFT BITUMEN TANK CONTAINER FLAME TUBE - 20FT HC HIGH CUBE: 25000-Litre UN Portable Tank T3

6058mm x 2438mm x 2896mm high cube, 2.65 bar test pressure, insulated, flame tube type, direct fire, heating by a diesel burner

Dimensions:
	Metric	Imperial
Capacity Tank	25000 LTR	(6604 US GALLONS) 5500 GALLONS
Maximum Gross Weight	30480 KG	67196 LBS
Tare	5950 KG	13118 LBS
Construction:
Working Pressure	1.75 bar	25 psi
Test Pressure	2.65 bar	39 psi
Relief Valve Set Pressure	2.2 bar / -0.21 bar/vac	32 psi / -3 vac/psi
Ambient Temp. Range	-40°C up to +200°C	-40°F up to +392°F
Maximum Cargo Temp	230°C	446°F
Shell Material	Mild Steel Q345D-GB/T1591-2008, 6,0 mm shell, 8,0 mm dish ends, the head is not less than 7,0 mm after forming.
Design Code / Approvals	ASME, Section VIII, Division 1 where applicable and IMDG T3, DOT UK, USDOT, UIC, IMO2, FRA, CSC, ADR, RID, CTC Transport Canada.
Standard Fittings:
Manlid	500mm (20") diameter, 6 point fixing, 14mm x 12mm seal, located centre.
Calibration	volumetric chart, nominal capacity 25,000 liters available.
Airline / Vapour	40MM (1½") ball valve, outlet 1½" BSP, s/s screw cap.
Relief Valve	65MM (2½") high flow flanged, operating pressure 2,2 bar. Capacity: 8710m3/hr.
Top Inlet	Blanked weld-in flange drilled 6x M12 holes @ 168 pcd, provision for optional fitting of 80mm (3") stainless steel butterfly valve. DN80, ASA 150 bolted blank flange outlet, 80mm (3") removable full-length syphon tube.
Bottom Discharge	Guard 100MM 4" ball valve - Outlet 3" BSP Flange with 3" Cam Lock Coupling and 3" Dust Cap.
Gaskets & Seals	Parts in contact with cargo, PTFE/Teflon.
Flame Tube Heating	One pair of two Φ159x6.0mm, Φ219x6.0mm.
Insulation	50MM (2") inorganic Rockwool (CFC free); 0,8 mm galvanized. st. cladding;Thermal conductivity: ≤ 0.044 w/(m2.k).
Document Holder / Earth	Fitted at the rear end, suitable for shipping documents, MSDS, etc. The Earth connection is located at the rear.
Data Plate / Markings	Stainless steel data plate detailing specifications fitted rear end.
Frame	The container frame shall be mainly composed of two (2) end frames, two (2) barrel supports, two (2) top side rails, two (2) bottom side rails, four (4) tank supports, and eight (8) corner fittings. Equipped with Reinforced Forklift Pockets (Empty Lift Only)
Walkway	400MM-wide non-slip steel. One longitudinal walkway and three short transverse walkways at the front and rear and adjacent to the rear of the manhole’s spill box. Aluminum walkways.
Handrail	(Optional) Intergraded at the top rail.
Temperature Gauge	Analog gauge fitted rear end: -20°C to +300°C. / -4°F to +572°F.
Color RAL	9005 or custom

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
