Stock Upon request
ISO Size 10FT ISO - 2991mm x 2438mm x 2591mm
Material Tank Body Stainless Steel 316L

Danteco offers T11 Type 10FT Offshore Tank Containers in various capacities. Offshore Chemical Tank Containers are approved by international statutory authorities for the safe transportation of various chemical General Purpose Liquids.

Tank containers are separated for two transportation purposes: tank containers for liquid chemical products and storage.
Offshore Chemical Tank Containers are approved by international statutory authorities for the safe transportation of various chemical General Purpose Liquids.
As permitted in the IMDG, ADR/RID for a UN portable Tank T11 Type

The vessel's operator must ensure that the commodity carried is listed under the applicable UN Portable Tank instruction and is in no way corrosive to 316/316L Stainless Steel.

Access & Tank Top

The framework acts as a ladder on all four sides. The tank top is fully enclosed for operators' safety and to prevent chains or slings from snagging.

Optional Extras

  • Electrical or Steam Heating
  • Remote Closures
  • Insulation and cladding
  • Level indication
  • Fittings to customer specification
  • Stainless Steel or Carbon Steel and lined vessel
  • Working pressure4 bar and 10 bar W.P. vessels
  • ISO Corner Castings
CAPACITY   FRAME SIZE  TARE  PAYLOAD  MGW
NOMINAL ACTUAL L x W x H mm KGS KGS KGS
  500 imp. Gals 2400 Litres 2150x1900x2050 1600 5400 7000
  600 imp. Gals 2870 Litres 2150x1900x2250 1800 5200 7000
1000 imp. Gals 4800 Litres  3048x1900x2250  2400 7600 10000
2000 imp. Gals  9200 Litres  2900x2400x2750  2200 12800 15000

10FT OFFSHORE TANK CONTAINER

OFFSHORE TANK: 1000 Gallons / 4542 Litre UN Portable Tank T11 TYPE
2750mm x 1850mm x 2470mm, General Purpose Chemical Tank Container,
Standard DNV 2.7-1, EN12079 Horizontal Tank in Rectangular Frame, 6.0 bar test pressure

Dimensions:
  Metric Imperial
Capacity Tank 4542 LTR 1200 (US GALLON) 1000 GALLON
Maximum Gross Weight 10500 KG 231497 LBS
Tare 2400 KG 5291 LBS
Construction:
Working Pressure 4.0 bar 58 psi
Test Pressure 6.0 bar 87 psi
Steam Working Pressure 4.0 bar 58 psi
Steam Test Pressure 6.0 bar 87 psi
Relief Valve Set Pressure 4.4 bar 63 psi

Design Temp. Range -40°C to +50°C -40°F to +149°F
Maximum Cargo Temp 50°C 248°F
Shell Material Stainless steel, ASTM A240 316 / 316L low carbon <0.03% DIN 17441 w1.4401. Cold rolled shell 2B finish. By regulations, the thickness is a nominal 4.4mm shell +0.1 corrosion allowance, 5.0 b/f forming ends, and equivalent 6mm mild steel.
Design Code / Approvals ASME VIII DIV 1., IMDG, ADR/RID, DNV 2.7-1, EN 12079.
Standard Fittings:
Manlid 1 x 460mm – 6-point fastening with TIR provision. c/w Swingbolts.
Vent Connection 3⁄4” BSP vent connection consisting of 3/4” BSP Weld in socket c/w 3⁄4” 316 S/S BSP elbow, 3⁄4” S/S Barrel nipple, 3⁄4” BSP Ball valve c/w a BSP Cap
Relief Valve 1 x 2 1⁄2” Super Maxi Highflow pressure vacuum relief valve, c/w flame gauze, Set pressure 4.4 bar, Set vacuum 0.21 bar.
Vent Connection 3⁄4” BSP vent connection consisting of 3/4” BSP Weld in socket c/w 3⁄4” 316 S/S BSP elbow, 3⁄4” S/S Barrel nipple, 3⁄4” BSP Ball valve c/w a BSP Capremovable full-length syphon tube.
Top Lid One piece and made from mild steel galvanized grating.
Bottom Discharge Outlet 1 x 3” 45 Deg High-Lift Bottom Outlet Assembly, c/w 2” Ball-valve and 2” BSP Outlet Flange c/w 1 x 3⁄4” sample valve c/w extension pipe, 3⁄4” ball valve, c/w cap, and chain.
Gaskets & Seals Parts in contact with cargo, PTFE/Teflon.
Padeyes ∅29 mm hole for 8.5-tonne shackle (Designed for 45-degree Sling angle).
Slings Included

Document Holder 2” carbon steel tube is 250 mm long welded to Cradle and fitted with a rubber cap with captivating wire.
Earthing Point Earth located at the rear, two off Earthing boss, 316L Stainless with M16 thread.
Data Plate / Markings To code and TIR requirements. (to be located on the Bottom Outlet side of the Tank)
Forklift Pockets 250mm x 150mm x 8mm Carbon Steel, with 1164mm between centers, c/w slots
Walkway / Grating To adequately cover all exposed fittings and prevent slings or chains from snagging per DNV 2.7-1. Made from mild steel galvanized grating.
Lader Located on outlet end, RHS. Anti-slip paint or tape is applied to the top surfaces of rungs.
Temperature Gauge 80mm dia dual scale -20°C to 100°C / 0 to 200°F
Level Gauge Available upon request.

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
