Stock	Upon request
ISO Size	20FT ISO - 6058mm x 2438mm x 2591mm
Material Tank Body	Mild / Carbon Steel

Approvals by Lloyd's Register, the Netherlands

20FT Double Wall Diesel Tank

Download Technical Details
info@danteco.com
+31 10 351 00 22
Approved by international statutory authorities for the safe transportation of Bitumen, Asphalt, Emulsion, and Heavy Crude Oil products

Danteco 20FT ISO T4 Double Wall Diesel Tank Containers are approved by international statutory authorities for the safe transportation of Diesel Fuel UN1202 and Kerosene oil products. Danteco supplies 25,200-litre, 20FT ISO, and 20FT HC diesel fuel tank containers. Our ISO diesel tank container is separated into five purposes, tank containers for diesel storage, deep sea shipping, short sea, road trucking, and rail transportation. Danteco Tank units are of the highest quality design and construction and conform strictly to the latest international approvals.

Danteco supplies 25,200-litre 20FT ISO and ISO 20FT HC diesel fuel tank containers, single-wall and double-wall skin. Our diesel tank containers are separated for five purposes: tank containers for diesel storage, short-sea, deep-sea shipping, trucking, and rail transportation. All Danteco tanks have the highest quality design and construction and conform strictly to the latest international approvals.

Please note that in certain exceptional cases, the containers operated by Danteco may have specifications that differ from the descriptions above.

Also, cargo in the container must conform to the dimensional regulations and laws stipulated by the host country; thus, payload capacity may be affected. For more information or assistance, please contact our customer service.

Capacity: 25200L / 5543 Gallons (6657 US Gallons)
T4 or T3 Type ISO 20FT and ISO 20FT HC
Full Frame Design
Double-wall and Single wall (double and single skin version)
UN T3 Code
Coating / Lining inside the barrel
Top Loading Point
TIR covers
DN80/100 Bottom Discharge
Approvals by Lloyds Register, the Netherlands.

DIESEL TANK 20FT ISO: 25200-Litre UN Portable Tank T3 and T4

Year manufactured: "new build."

Dimensions:
	Metric	Imperial
Capacity	25200 LTR	5543 US GALLONS
Maximum Gross Weight	30480 KG	67196 LBS
Tare	5950 KG	13118 LBS
Construction:
Working Pressure	1.75 bar	25 psi
Test Pressure	2.65 bar	39 psi
Relief Valve Set Pressure	2.2 bar / -0.21 bar/vac.	32 psi / -3 vac./psi

Ambient Temp. Range	-40°C up-to +130°C	-40°F up-to +266°F
Maximum Cargo Temp	130°C	266°F
Shell Material	Mild Steel Q345D-GB/T1591-2008, 6,0 mm shell, 8,0 mm dish ends, the head is not less than 7,0 mm after forming.
Design Code / Approvals	ASME, section VIII, division 1 where applicable, and IMDG T3, DOT UK, USDOT, UIC, IMO2, FRA, CSC, ADR, RID, CTC Transport Canada
Standard Fittings:
Man-lid	Guard brand 500mm (20") diameter, 6 point fixing, 14mm x 12mm seal, located center
Calibration	volumetric chart, nominal capacity 25,000 liters available
Airline / Vapor	Guard brand 40MM (1½") ball valve, outlet 1½" BSP, s/s screw cap.
Relief Valve	Guard brand 65MM (2½") high flow flanged, operating pressure 2,2 bar. Capacity: 8710m3/hr.
Top Inlet	Blanked weld-in flange drilled 6 M12 holes @ 168 pcd, provision for optional fitting of 80mm (3") stainless steel butterfly valve. DN80, ASA 150 bolted blank flange outlet, 80mm (3") with dust cap
Bottom Discharge	Guard brand 100MM 4" ball valve - Outlet 3" BSP Flange with 3" Cam-Lock Coupling and Dust-Cap.
Gaskets & Seals	Parts in contact with cargo, PTFE/Teflon.
Insulation	N/A of upon request
Document Holder / Earth	The fitted rear end is suitable for shipping documents, MSDS, etc. The Earth is located at the rear.
Data Plate / Markings	Stainless steel data plate detailing specifications fitted rear end.
Frame	The container frame shall be mainly composed of two (2) end frames, two (2) barrel supports, two (2) top side rails, two (2) bottom side rails, four (4) tank supports, and eight (8) corner fittings.
Walkway	400MM-wide non-slip steel. One longitudinal walkway and three short transverse walkways at the front and rear and adjacent to the rear of the manhole’s spill-box. Aluminum walkways
Handrail	(Optional) Intergraded at the top rail
Temperature Gauge	Analog gauge fitted rear end: -20°C to +150°C. / -4°F to +266°F
RAL Color / Paint Exterior	9010 - White or Custom Color

Actual measurements and specifications may vary and are subject to confirmation.
Tank containers are supplied per the manufacturer's (Danteco Industries BV) general trading terms and conditions.
